| Brand Name: | zhongchi |
| Model Number: | ZC450F |
| MOQ: | 1Set |
| Price: | $2000-12000 |
| Payment Terms: | TT/LC |
The machine provides efficient and reliable performance in edge banding operations. It has the following
specifications:
| Working thickness | 10-60mm |
| Min. working width | ≥60mm |
| Min. panel length | ≥160mm |
| Feeding speed | 18-24m/min |
| Tape thickness | 0.4-3mm |
| Air pressure | 0.6Mpa |
| Total power | 16.8KW |
| Voltage | 380v,50hz, 3phase/220v/415v/440v |
| Weight | 2600kg |
| Overall size | 6800*1100*1600mm |
The applicable products for this tool are solid wood panels, fibreboard, particleboard, MDF, and other panels
and panel furniture edges. The edges can be made of various materials such as PVC, polyester, melamine,
and wood.
This tool delivers a wide range of results, including high automation, high efficiency, high precision, and high
aesthetics, making it an ideal choice for various woodworking projects.
The tool is built on a laser-cut steel plate base, and its welded body is designed to prevent deformation, increase
stability, and ensure fine work in each processing department. Moreover, the processing components include
imported motors and high-quality electrical components, resulting in a reliable and durable tool.
Packing and Shipping:
Meeting:
Work Shop:
Feedback:
- Edge sealing firm: The edge sealing strip can tightly adhere to the board due to even glue application,
strong adhesive force, and minimal peeling off. By using advanced adhesive structure edge banding machines,
double-sided adhesive coating is achieved, further increasing the firmness of edge banding strips. This
ensures that the edge banding strips of furniture and other wooden products will not fall off during their
long-term use.
- Smooth and flat edges: The edge banding machine offers precise cutting, trimming, and scraping functions,
which remove excess parts on the edge banding strip, eliminate ripple marks, make the edges of the board
smooth, and improve the appearance quality and touch of the product. After polishing treatment, the edges of
the board after edge sealing are more visually appealing, enhancing the overall beauty of the product.
- High dimensional accuracy: By relying on a precise positioning system and stable movement of processed
components, the length and width of the edge banding can be ensured to match the edge of the board, with
minimal error. This is crucial in improving the dimensional accuracy and assembly accuracy of wooden products.
- High degree of automation: The fully automatic edge banding machine can achieve a series of operations such
as automatic feeding, gluing, edge banding, cutting, and trimming, greatly reducing manual intervention and
improving production efficiency. Machines can work faster compared to traditional manual edge banding, completing
a large amount of edge banding work in a short period of time, meeting the needs of large-scale production.
- Strong continuous working ability: The edge banding machine has high stability and reliability, and can operate
continuously for a long time, reducing production interruptions caused by machine failures or downtime maintenance.
This improves equipment utilization and production efficiency.
- Adjustable parameters: The edge banding machine can flexibly adjust adhesive amount, feeding speed, trimming
depth and other parameters according to different board materials, thicknesses, edge banding types, and other
factors. This meets different edge banding needs, and even personnel without professional technical background
can proficiently operate the machine after simple training.
- Easy to maintain: The structural design of the machine is reasonable, and each component is easy to disassemble
and install, making it convenient for daily maintenance. For instance, components such as glue pots can be easily
disassembled and cleaned to avoid residual glue affecting the quality of edge sealing, reducing equipment maintenance
and time costs.
- Strong adaptability of the board: The edge banding machine is suitable for various types of wooden boards, such as
particleboard, medium density board, solid wood board, etc. Effective edge sealing treatment can be carried out,
whether it is flat board or irregular board, meeting the production needs of different types of wooden products.
- Good compatibility of edge banding: The machine can be compatible with edge banding of different materials and
specifications, such as PVC edge banding, melamine edge banding, wood banding, etc. This provides users with
more choices and facilitates enterprises to produce according to different product requirements.
- Reduce labor costs: Automated edge banding operations reduce reliance on manual labor and lower labor costs
for businesses. Meanwhile, the efficient production of machines can increase the production capacity of enterprises
and increase economic benefits.
- Reduce material waste: Accurate processing can reduce the waste of edge banding, improve material utilization,
and reduce production costs.
The machine has a working thickness range of 10-60mm and requires a minimum working width of 60mm. It also
has a minimum panel length requirement of 160mm. The feeding speed is fast, ranging from 18 to 24m/min,
enabling fast and efficient work. The tape thickness supported by the machine is from 0.4 to 3mm.
To ensure reliable operation, the machine requires air pressure of 0.6Mpa. The total power required is 16.8KW,
and the voltage is 380v, 50hz, 3phase. The main drive motor requires power of 3.7KW.
This machine is heavy, weighing 3000kg, designed to withstand heavy and prolonged use. It has an overall size
of 6800*1100*1600mm, providing ample space for the panel to be worked on.
Applicable Products:
The following types of panels and panel furniture edge can benefit from our edge processing technology: solid
wood panels, fibreboard, particleboard, MDF and others. The edge can be made from different materials such
as PVC, polyester, melamine and wood, just to name a few.
Achieve Results:
Our edge processing solutions are designed to deliver exceptional results, such as a high degree of automation,
high efficiency, high precision and high aesthetics. Our equipment is capable of handling large volumes of panels
with ease, while ensuring consistent and perfect processing every time.
Structural Advantages:
Our equipment is built to last, thanks to its robust design and cutting-edge features. The machine is built on a
laser-cut steel plate base, which provides a solid foundation for the welded body. The machine is designed to
ensure that it maintains its shape and size throughout its use, providing stability and precision. The machine is
also equipped with high-quality components, including imported motors and top-of-the-line electrical components,
which guarantee optimal performance and reliability.
The Wood Edge Banding Machine is a high-quality product designed to provide efficient and reliable edge
banding for wood materials. Our technical support and services include:
We are committed to providing exceptional customer service and technical support to ensure that our customers
get the most out of their Wood Edge Banding Machine.
Frequently Asked Questions about Wood Edge Banding Machine
Q: What is the brand name of this machine?
A: The brand name of this machine is zhongchi .
Q: What are the model numbers available for this machine?
A: The available model numbers are ZC450B, ZC450F, ZC300B, and ZC360B.
Q: Where is this machine made?
A: This machine is made in China .
Q: Does this machine have any certification?
A: Yes, this machine is CE certified .
Q: What is the minimum order quantity for this machine?
A: The minimum order quantity for this machine is 1 set .
Q: What is the price range for this machine?
A: The price range for this machine is $2000-12000 .
Q: What is the delivery time for this machine?
A: The delivery time for this machine is 10-15 days .
Q: What are the payment terms for this machine?
A: The payment terms for this machine are TT/LC .
Q: What is the supply ability of this machine?
A: The supply ability of this machine is 200 sets per year .
|
